Material Turning Heat Into Electricity; A New Material Breaks Record

A new type of material discovered generates electrical current very efficiently from the temperature differences, which allows sensors & small processors to supply themselves with energy wirelessly.

The thermoelectric materials can convert heat into electrical energy. This is due to the Seebeck effect: If there is a temperature difference between the two ends of such material, the electrical voltage can be generated & current can start to flow. The amount of electrical energy that can be generated by a material at a given temperature difference is measured by the ZT value: The higher the ZT value of a material, the better is its thermoelectric properties.

The best thermo-electrics to date were measured at ZT values of around 2.5 to 2.8. Researchers at TU Wien (Vienna) have now succeeded in developing completely new material with a ZT value of 5 to 6. This is a thin layer of iron, vanadium, tungsten & aluminum applied to a silicon crystal.

The new material is so effective that it could be used to provide energy for sensors or even small computer processors. Instead of connecting small electrical devices to cables, they could generate their own electricity from temperature differences. This new material has now been presented in the journal Nature.

Prof. Ernst Bauer from the Institute of Solid State Physics at TU Wien said a good thermoelectric material must show a strong Seebeck effect, and it has to meet two important requirements that are difficult to reconcile. On the one hand, it should conduct electricity as well as possible; on the other hand, it should transport heat as poorly as possible. This is a challenge because electrical conductivity and thermal conductivity are usually closely related, he added.

At the Christian Doppler Laboratory for Thermoelectricity, which Ernst Bauer established at TU Wien in 2013, different thermoelectric materials for different applications have been studied over the last few years. This study has now led to the discovery of a, particularly remarkable material—a combination of iron, vanadium, tungsten & aluminum.

Bauer said the atoms in this material are usually arranged in a strictly regular pattern in a so-called face-centered cubic lattice. And the distance between 2 iron atoms is always the same, and the same is true for the other types of atoms. The whole crystal is therefore completely regular, he explained.

However, when a thin layer of the material is applied to silicon, something amazing happens: the structure changes radically. Although the atoms still form a cubic pattern, they are now arranged in a space-centered structure, and the distribution of the different types of atoms becomes completely random. 2 iron atoms may sit next to each other, the places next to them may be occupied by vanadium or aluminum, and there is no longer any rule that dictates where the next iron atom is to be found in the crystal, explains Bauer.

This mixture of regularity and irregularity of the atomic arrangement also changes the electronic structure, which determines how electrons move in the solid. The electrical charge moves through the material in a special way, so that it is protected from scattering processes. The portions of charge traveling through the material are referred to as Weyl Fermions, says Ernst Bauer. In this way, the very low electrical resistance is achieved.

Lattice vibrations, on the other hand, which transport heat from places of high temperature to places of low temperature, are inhibited by the irregularities in the crystal structure. Therefore, the thermal conductivity decreases. This is important if electrical energy is to be generated permanently from a temperature difference–because if temperature differences could equilibrate very quickly and the entire material would soon have the same temperature everywhere, the thermoelectric effect would come to a standstill.

Such a thin layer cannot generate a particularly large amount of energy, but it has the advantage of being extremely compact and adaptable, said Ernst Bauer. Researchers want to use it to provide energy for sensors and small electronic applications. The demand for such small-scale generators is growing quickly: In the “Internet of Things,” more & more devices are linked together online so that they automatically coordinate their behavior with each other. This is particularly promising for future production plants, where one machine has to react dynamically to another.

If we need a large number of sensors in a factory, we can’t wire all of them together. It is much smarter for the sensors to be able to generate their own power using a small thermoelectric device, said Bauer.
